Задължителен е минимум 3-годишен лиценз DNA Essentials!

Спецификации

Суич, тип
Fixed Port
Общ брой портове
28
Основни портове, тип
24 ports full PoE+ (8 mGig ports up to 10G, 16 ports up to 1G)
Power Over Ethernet (PoE)
IEEE 802.3at PoE+ (up to 30W per port); Available PoE power with single primary power supply (PWR-C5-600WAC): 370W
Uplink портове
4x 1/10G fixed uplinks
Свободни (10GB) слотове
-
Управление
WebUI is an embedded GUI-based device-management tool that provides the ability to provision the device, to simplify device deployment and manageability, and to enhance the user experience
Stackable
Stacking bandwidth: 160 Gbps
Fans
Fixed redundant
Захранване
PWR-C5-600WAC
Routing
Advanced
Памет (Flash, RAM)
Flash: 4 GB; DRAM: 4 GB; Packet buffer: 12MB
Капацитет за маршрутизиране/превключване, Gbps
272 Gbps; Switch capacity with Stacking: 352 Gbps
Пропускателна способност, Mpps
214.28 Mpps; Forwarding rate with Stacking: 262 Mpps
MAC адреси
32 000
VLAN (брой, стандарти)
4; VLAN IDs: 4096; CISCO-PRIVATE-VLAN-MIB, CISCO-VLAN-IFTABLE-RELATIONSHIP- MIB, IEEE 802.1Q VLAN
QoS
Superior QoS includes granular wireless bandwidth management and fair sharing, 802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification, SRR scheduling, Committed Information Rate (CIR), eight egress queues per port
L2 мрежови стандарти
IEEE 802.1Q, IEEE 802.1D (STP); RSTP, IEEE 802.1w; MSTP, IEEE 802.1s; PVLAN; IEEE 802.3ad (LACP); LLDP; VTP; BPDU Guard
L3 мрежови стандарти
IP Routing (Static, RIP, OSPF, EIGRP), VLAN Routing (SVI, Routing Between VLANs); Multicast Routing (PIM, IGMP); BGP; IPv6; HSRP; VRRP; GLBP; ACLs; PBR
IPv6 functionality
IPv6 routing entries: 2000; Ipv6 routing (using OSPFv3 and EIGRPv6); IPv6 addressing
Сигурност
AES-128 MACsec encryption; Secure Segmentation with Software-Defined Access; Cloud Security - Umbrella Integration
Размери (Ш, Д, В), mm
445 x 350 x 44 mm
Опция за монтаж
Rackmount
Други
Network Essentials licensing
Гаранция, м.
99 месеца
Тегло, кг.
6 кг.
